CO2 Laser Cutting Machine

Auto-Feeding Laser Cutting Machine Series CMH1810C-FT-A

Auto-Feeding Laser Cutting Machine Series CMH1810C-FT-A

Introduction

Electric heads(Two) as optional for separate and independent working. CCD camera , pen, large-format vision system and projecting functions areoptional for better cutting experience. Epsilon type of conveyor as standard , other type conveyor as optional . For the epsilon type of conveyor, the front&back presser, as an optional device, can be applied together to ensure the cutting accuracy. Multiple-layer of material feeding is available. Auto-feeding and unloading system, the two laser heads distance adjust automatically, save time; Nesting software is optional, support mixed nesting, edge-sharing cutting, save material; Laser head distance can be adjusted automatically, depending on the nesting result.

Inquiry

Sample

Cloth shoes laser cutting
Glove cutting
Hair callar cutting
Hollowing-out of home textile fabric
Skirt hollowing
Slipper cutting
Toy cloth cutting
Upper vamp hollowing
Parameter

Parameter

  • Modle
    CMH1610C-FT-A
  • Laser power(W)
    60~130
  • Working area(mm)
    1480*1000
  • Overall dimension(mm)
    2210*2120*1150
  • Weight (kg)
    850
  • Conveyer
    E-type conveyor / herringbone type conveyor
  • Laser head
    double
  • Speed (m/min)
    0~18
  • Supply voltage (m/min)
    AC220V±10%
  • Working environment
    Temp:5~40℃, Humidity:5~80% Clean, less dust
  • Modle
    CMH1810C-FT-A
  • Laser power(W)
    60~130
  • Working area(mm)
    1680*1000
  • Overall dimension(mm)
    2410*2120*1150
  • Weight (kg)
    950
  • Conveyer
    E-type conveyor / herringbone type conveyor
  • Laser head
    double
  • Speed (m/min)
    0~18
  • Supply voltage (m/min)
    AC220V±10%
  • Working environment
    Temp:5~40℃, Humidity:5~80% Clean, less dust

*Some of the above models can be equipped with electric head, small format camera, large format camera and projection alignment function, please inquire for details; * The above working format is a single-head effective cutting format, and the multi-head format is subject to actual conditions;

Feature

  • Conveyor features: Good edge control,keep flat moving, strong cnveyor and stable;
  • Epsilon-type aluminum conveyor enjoy light weight, stable structure, no distortion, good flatness. Easy for maintenance and replacement piece by piece. It enjoys long lifetime, high stability and low cost ;
  • The upper cover shrinks inside. Collection does not need to stop the machine . The efficiency is high. The processing zoneis separated from the receiving area and the safety is high.
