3D Five-Axis Fiber Laser Cutting Machine CMT3015

3D Five-Axis Fiber Laser Cutting Machine CMT3015

Introduction

High-strength casted light aluminum beam,good dynamic performance,fast response speed with accurate positioning;High gantry type structure design, high rigidity high speed and high efficiency cutting;Smart 5-axis CNC system, easy for flexible production;Han’s Group Self-developed high precision optical laser head, to guarantee high quality cutting Fully enclosed design, equipped with access control security protection functions to ensure safe operation; for automobile thermal forming parts,3D metal forming parts, curved parts and special-shaped tubes.

Sample

Automobile cross member cutting

Automobile rear panel cutting

Automobile sheet metal parts cutting

Automobile sunroof cutting

Parameter

Parameter

Modle

CMT3015
Working area(mm)

3000×1500×850mm
Laser power(W)

1000~6000w
Laser wavelength

1064nm
Maximum accelerated

1.0G
MaximumMoving speed

±100m/min
Positioning accuracy

±0.05mm
Repeated positioning accuracy

±0.03mm
Weight(Kg)

12000~18000kg

Feature

Fully enclosed protection cover, comply with European safety standard;
Equip with high torque servo motor and high precision imported reducer, highefficiency, favorable dynamic characteristics;
High rigidity welded body with die-cast aviation aluminum gantry, improve thegantry strength and much lighter, enjoy good stability & durability;
Laser application parameterize design, more user-friendly;
Low accessing gas consumption by precision control, to ensure the low runningcost.
